Acrylic Glove Box
The acrylic Glove box is designed to view the samples and testing from each side and each angle. Yatherm, Offers small and big size customized and tailor-made glove boxes at a reasonable price. Gloves boxes are used to give an inert atmosphere to the testing of samples. This cabinet saves the testing of our samples from oxidation. This is a lightweight cabinet with high-quality latex gloves, KF -25 connector, big size main chamber door & antechamber with a Vacuum gauge.
Yatherm has five models in transparent plexiglass with almost similar design and different features. One of our Acrylic Glove Box models has a pressure controller and another one is without pressure controller. We can customize our standard models for working more than a single person by simply increasing the dimension & number of gloves.
Glove Box Diagram:
Features:
| Imported acrylic Construction | Transparent clear view |
| Vacuum air locker and side door | Chemical resistance |
| Prevent moisture absorption | Portable size Light Weight |
| Easy to clean interior | Scratch resistance cabinet |
Specifications:
| Model | YS/TGB-2 | YS/TGB-2Y |
| Pressure Controller | Without | Yes |
| Digital Vacuum Pressure Gauge | Fixed In Antechamber | Range: 0 to 101Kpa (Absolute Pressure) |
| Valves | 3 Manual valves | Three manual valves Two solenoid valves |
| Construction | Acrylic sheet | |
| Glove Box Dimension (mm) | 1150 L x 500 W x 500 H | |
| Containment Chamber(mm) | 875 L x 480 W x 500 H | |
| Air Lock Chamber(mm) | 230 L x 230 W x 230 H | |
| Plastic thickness | 6 mm with Support | |
| Side Door size | 400 mm diameter | |
| Glove port’s size | 151 mm Dia | |
| Pressure Range | Main Chamber – 90 Kpa ˜ 120 Kpa Air Lock Chamber – 10 Kpa ˜ 120 Kpa |
|
| Glove Ports | Two-Port Glovebox (One Operator) | |
| Standard accessories
(Inclusive) |
– Analog Pressure gauge: 01 No. – Internal plug strip: 01 No. – Latex Gloves: 01 pair |
|
Plexi Glass Small Glove Box YS-TGB-1
This is the smallest size glove box with two latex gloves, Transparent Plexi Glass & manual Solenoid Valve. This type of glove box is used for contamination-sensitive samples in an inert atmosphere. Glove Box provides oxygen and moisture free environment to avoid oxidation.
Application
- Semiconductor laboratory
- Battery research
- Chemical Industry
- Pharmaceutical Industry
- Defense Laboratories
Specification：
| Model | Size (mm) | Glove Ports | Glove Port Size (mm) | Thickness（mm） | Net Weight （kg） |
| TGB -1 | 312(L) x 407(W) x 400(H) | 2 | Ф150 | 6 | 15 |
Humidity-Controlled Transparent Glove Box – TGB – 2C
Yatherm TGB-2C equipped with an automatic humidity controller and pressure controller for humidity and oxidation-sensitive products. This controller is very useful in dehumidifying and purging of nitrogen gas to make an inert atmosphere.
Features:
- LED display
- 1-60%RH adjustable
- Relative humidity deviation is ±2%RH
- High Dehumidifying Speed
- Low relative Humidity up to 1% RH
- Microcontroller Unit for digital & real-time data
- Solenoid valve will open to purge the gas in case of deviation of humidity from the set point
Acrylic Glove box Specifications:
| Model | TGB-2C |
| Air Locker Chamber Size (in mm) | 240 L x 240 W x 240 H |
| Containment Chamber Size (in mm) | 900 L x500 W x500 H |
| Product Overall Size (in mm) | 1250 L x 500 W x 500 H |
| Option | Vacuum Pump /Nitrogen Cylinder/ Gloves |
Clean Room Glove Box with HEPA Filters – TGB-2D
Now we have come with innovation and our new model of glove box fitted with HEPA filter. This Glove Box is specially designed for cleanroom operations. Our HEPA filters are made in JAPAN with the easily replaceable arrangement.
Features:
- Steel clamp with Gloves
- 480 CFM impeller Blower
- HEPA Filter with 99.9% with 0.3micron
- ULPA filters as per requirement
- All these parts are mounted on hard Polypropylene
Transparent Glove Box Specifications:
| Model | YS-TGB – 2D |
| Air Locker Chamber Size (in mm) | 240 L x 240 W x 240 H |
| Containment Chamber Size (in mm) | 900 L x500 W x500 H |
| Product Overall Size (in mm) | 1250 L x 500 W x 500 H |
| Option | Closed-loop Type HEPA Glove Box / Vacuum Pump /Nitrogen Cylinder |
