Photo Stability Test Chamber

Photo Stability Test Chamber-walk-in stability Test Chamber- Stability Test Chamber

Photo Stability test chambers are specially designed with international standards for the pharmaceutical industry. Yatherm Photostability test chambers follow WHO guidelines, FDA Standards & ICH standards. Photo Stability test chamber name suggests chamber performing with lights and UV lights testing w/ Fluorescent illumination. Stability test chamber equipped with rustproof thick steel grade 304, high-quality illumination lights, Humidity system with Digital Humidity controller. We are one of the reputed Test Chamber Manufacturers in India with timely delivery & great after-sales support. Sales support is very important in the field of the test chamber because of its continuous operation.

Yatherm is reckoning for test chamber manufacturing since 2005 with the help of experienced engineers. We believe in quality and precise controlling of the features like Humidity and temperature inside the chamber. We are manufacturing and delivering the best quality made in India product worldwide for pharmaceutical industries. Yatherm photostability test chambers are used in research organization for developing a new molecule. We design equipment as Per ICH Q1B guidelines option 2 which specifically deals in ultraviolet and Visible light testing.

Yatherm photo Stability test Chambers are designed for regular and continuous operation for 30 days, 41 days & 90 days. Our Photostability test Chambers undergoes In-house testing where we perform FAT (factory Acceptance test) with Validation and calibration. We perform Temperature and Humidity uniformity test & high/low temperature with humidity testing. Yatherm offers DIN sensors for temperature and Humidity which makes Stability test chamber precise and accurate. We are offering our test chambers to MEA (Middle East Africa), Asia, Europe & America at the best price. Our stability test chambers are CE & GMP compliance with the best price in India. You can post your requirement to our communication address for complete understanding and price quotations.

Features:
  • ICH, WHO Guideline, and USFDA Standards
  • Temperature tests  Range from +5°C to +65°C
  • Climatic tests range from +10°C to +50°C
  • Humidity range from 20%RH to 90%RH With Low And High Humidity Testing
  • Availability of volumes – 200, 400, 600, 800, 1000 and 2000 liter
  • 3.5″ ,4″, 5″ & 7″ inches color touch panel
  • Safety temperature Thermostat
  • Automatic shut off after specified exposure level
  • HCFC free compressor
  • Rust Proof SS 304/SS 316 L grade Chambers
  • DIN sensors / Class A sensors
  • Printer interface and data storage facility, LUX and UV mete
  • Air-cooled hermetic refrigeration system
  • Lockable doors with key lock System
  • High & Low-temperature Alarm system in As per GAMP 4
  • Water Tank for Humidity generation – 20 liters
  • Lockable Castor wheels
  • RS 485 Computer interface
  • 220V Power Supply
  • White coated, similar to RAL 9016, sheet steel exterior
  • Factory calibration of two temperature and two climatic values
  • Manufactured in India



Models & Capacity:

Yatherm offers standard Models ranging from 200 Liters capacity to 2000 Liters & we are having expertise in making customized equipments. We are always ready to provide bigger sizes according to our customer’s requirements.

Illumination:

Illumination is a very important factor for the photostability test chamber for photostability testing.  Our Photostability test chambers are fully compliance with ICH guidelines Q1B part 2 which provides illumination testing procedure details for Photostability test chambers. We offer fluorescent LED Milky white light with 4 million lux hours & UV lights for proper exposure inside the working test chamber. Yaherm programmable controllers are equipped with controlling light feature for both the lights with power load.

Controlling System:

Our test chambers come with 4 to 7 inches HMI with PLC operation for controlling light, temperature, timer & humidity. We offer an advanced quality controlling system with our test chamber to meet the latest features. Yatherm provides a microprocessor-based PID controller for economy test chambers with quality sensors. Photostability test chambers are highly precise and accurate equipment works with the help of DIN sensors. Class A Sensors/ Din sensors are master sensors that provide precise and accurate information to the controller. PLC with HMI comes with three layers password protection & test chamber door is equipped with door lock key.



Construction:

We have certain standards for the manufacturing of test chambers in our factory. Our test chambers are made up of rustproof stainless steel 304 grade with curved corners for easy cleaning and maintenance. Yatherm offers SS304 & SS 316 construction for the inner and outer chamber with an eco-friendly HCFC free cooling system. We provide double-walled construction with 80 – 100 mm PUF insulation to avoid cooling, heating, and humidity from the chamber. Yatherm photostability test chambers are mounted on 4 lockable caster wheels for easy mobility.



Humidity Generation:

Inbuilt SS 304 small chamber with low water cut off, ISI mark SS 316 water heater for uniform heating, water input valve & Water drain valve. Yatherm test chambers humidity reservoirs are designed within the open chamber for accurate humidity for high and low humidity operations. ISI mark u shape water heaters have a long life and powerful humidity generation.



Technical Specification
Yatherm  Model Photo 600Photo 1000Photo 2000
Temperature range:

Temperature tests

Climatic tests

+5°C to +60°C

+10°C to +50°C

+5°C to +60°C

+10°C to +50°C

+5°C to +60°C

+10°C to +50°C

Humidity range (between +10°C to +50°C)20%RH to 90%RH20%RH to 90%RH20%RH to 90%RH
Chamber volume gross (approximately)600 liter1000 liter2000 liter
Useable shelf area (approximately)2.07 m23.55 m26.21 m2
Standard shelves61018
Minimum space between shelves30 mm30 mm30 mm
Interior dimensions (w x dx h)620 mm x
685 mm x
1300 mm
1150 mm x
685 mm x
1300 mm
2034 mm x
685 mm x
1300 mm
Maximum Exterior dimensions (w x dx h)783 mm x
1061 mm x
1995 mm
1403 mm x
1038 mm x
1995 mm
2156 mm x
1040 mm x
2001 mm
Electrical connection1/N/PE AC 220/230 V ±10% 50/60 Hz1/N/PE AC 220/230 V ±10% 50/60 Hz1/N/PE AC 220/230 V ±10% 50/60 Hz
Weight200 kg250 kg355 kg
